Busbar Application in Rail Trasit
The proven quality of our products is based on internationally leading design and manufacturing concepts, combined with state-of-the-art production equipment. Our talented engineers have many years of experience in producing busbars.Whether our customers wish to develop a completely new solution, optimize a design or just produce their existing design under optimized conditions, we are your dedicated partner for laminated busbars.
Project: 350km/h Standard EMU Parameter: Voltage: 3800V AC Current: 1000A AC Dielectric Strength: 9.6KV -AC-60s, No breakdown, no flicker. Partial Discharge: AC 3610V(＜10PC) |
 Project: HXD2B Electric LocomotiveLaminated Busbar Parameters: Voltage:2200V Current:1650V Dielectric Strength: 5.6 KV -AC-60s, No breakdown, no flicker. Partial Discharge: AC 2300V(＜10PC) |
Project: South-Africa D45Internal-combustion locomotive Parameter: Voltage: 2000V Current: +/-400A UVW 650A Dielectric Strength: 6.0KV -AC-60s, No breakdown, no flicker. Partial Discharge: AC 1800V(≤10PC) |
Project: Bushan Subway Line2 Laminated Busbar Parameter: Voltage: 1500V Current: 800A Dielectric Strength:5.4KV -AC-60s, No breakdown, no flicker. |
